| Printer model | XP-470B | |
| Printing method: | direct thermal printing/ thermal sensitive |
| printing resolution: | 203dpi 8 dots/ mm |
| pirnt width: | 108mm |
| print speed: | 127mm ( 4") |
| memory: | 4MB FLASH RAM, 8MB SDRAM / Micro SD Flash reader can extend to 4GB. |
| Interface | USB 2.0 ( standard) / RS-232 ( Factory option) , Etherne t ( Factory option) bluthtooth( Factory option) , Wireless WIFI ( Factory option) |
| Power supply: | Circumscribed general switch power supply Imput: AC 100-240V , 1 A 50-60HZ output: DC 24v 2.5A , 60W |
| Operation switch, button , LED | Power off switch, feed, LED light ( 3 colors red , purple , blue) |
| Sessor | Black mark ( reflective location can be adjustable)
Printer head open sensor |
| In-built typeface | 8 kinds bitmap typeface/ or can use windows fonts download from Internet. |
| Barcodes: | 1D bar code：Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13,
EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST
2D bar code：PDF-417, Maxicode, DataMatrix, QR code |
| Character enlarge/ rotary: | Horizontally and vertically can amplified 1-10 times, rotary printing ( 0°、90°、180°、 270°) |
| Printer Language: | TSPL ( EPL, ZPL, DPL) |
| Medium ( paper) type | Continuous paper, distance paper, fold , perforated tags etc |
| Medium width: | 20mm- 118mm (0.78"- 4.6") |
| Medium thickness: | 0.06 ~ 0.25 mm (2.36 ~ 9.8 mil) |
| label roll inner core | 25.4 ~ 76.2 mm (1"~ 3") |
| Print label length: | 10 ~ 2,286 mm (0.39"~ 90") |
| Accessory: | > Windows label editoring software, driver and operation manual CD > quick -installation guideline > USB transmission line > Power supply line > Circumscribed Voltage automatically exhange power supply server
> rewinder roller, paper fixation panel *2 |
| Factory: (Alternative) | 1. Real time clock 2. label peeling off module |
| Customers (alternative) | 1. Exernal hanger and 1 inch core paper roller 2. External label hanger extend panel 3. Electronic single box |
| Safety regulation: | FCC、CE、 CCC、CB |
| Weight: | 2.15KG |
| Dimension: | 240(D) x 212(W) x172(H)mm |
| working environment : | 5～40℃ （41~104°F）, Humidity 25－85%RH ( uncondensed) |
| Storage: | －40～60℃ （-40~140°F），Humidity 10 ~ 90% ( uncondensed) |
