auto cutter machine USB High quality TTP2410 TTP 346MU thermal barcode label printer

Model NO.
TTP 346MU TTP 2410MU
Price:
USD 999.00-1,280.00 / piece
Delivery:
FOB
Minimum order quantity:
1 piece
Supply Ability:
300 piece / Quarterly
Country of Origin:
Shenzhen guangzhou foshan
Quantity:
  • Products Status:Stock
  • Style:Black And White
  • Use:Barcode Printer
  • Interface Type:USB
  • Place of Origin:CN;GUA
  • Type:thermal transfer printer, label printer
  • Max Paper Size:104mm
  • Black Print Speed:356mm/ sec
  • Color Print Speed:NO
  • Max. Resolution:300dpi 200dpi 600dpi
  • Brand Name:TSC
  • Model Number:TTP 346MU TTP 2410MU
Product Description

auto cutter machine USB High quality TTP2410 TTP 346MU thermal barcode label printer

The TTP-2410MU Series features the best print quality TSC has ever offered in a midrange printer thanks to new printhead technology combined with faster processors and upgraded firmware. We call our enhanced print quality"Thermal Smart Control"™ which tracks and precisely calculates the duration that each pixel needs to be heated to provide accurate, crisp and clear labels every time, whether you are printing one label at a time or thousands of labels in a batch.

Applications:


*Industrial-duty Printing
*Healthcare Patient Safety
*Compliance Labeling
*Work In Process
*Order Fulfillment
*Distribution
*Shipping/ Receiving
*Ticketing
*Electronics & Jewelry Labeling

Printer model
TTP-2410 MU
TTP-346MU
TTP644MU
Printing resolution
8 dots/mm (203 DPI)
12 dots/mm (300 DPI)
24 dots/mm (600 DPI)
Printing method
Thermal Transfer printing & Direct Thermal
Max. print speed
356 mm (14")/sec
254 mm (10")/sec
102 mm (4")/sec
Max. print width
4.09"104mm
Printer shell
Aluminium alloy structure , metal shell , with an open window design
Physical Dimension
270 mm (W) x 308 mm (H) x 515 mm (D)
10.63"(W) x 12.13"(H) x 20.28"(D)
Weight
15KG (33.07 lbs)
Label Capacity Diameter
208.3 mm (8.2") OD
Ribbon
600 m max. OD 90 mm, 1"core (inking outside or inside suitable)
Ribbon width
25.4 mm ~ 114.3 mm (1"~ 4.5")
Processor
32 bit CPU
Memory
• 128 MB Flash memory
• 128 MB SDRAM
• SD Flash card with expandable card extend up to 32 GB
Communication interface
• Serial interface RS-232
• Parallel port• USB 2.0
• In-built Ethernet Server
• USB host, support stand-alone operation keyboard, and barcode scanner
• GPIO (alternative option)
• Bluetooth (user alternative option)
• 802.11 b/g/n Wireless transmission (user option)
Power Supply
In-built Power Voltage automatically switching power supply
• Input: AC 100-240V, 2A, 50-60Hz
• Output: DC 24V, 5A, 120W
Operation panel
Display 128*64 Pixel backing light
Operation switch-off, button
one switch-off power supply, 6 buttons ( Menu, Pause, Feed, Up, Down, Select)
Sensor
Label distance sensor ( Penetration, location adjustable)
black line sensor ( reflective , location adjustable)
ribbon end-up usage
ribbon transmit speed
printing head up and down style sensor
Real time clock
standard
In-built typeface
• 8 alpha-numeric bitmap fonts
• Monotype Image® true type font engine with one CG Triumvirate Bold Condensed scalable font
Barcode
• 1D bar code

Code 39, Code 93, Code 128UCC, Code 128 subsets A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13,
EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST,
GS1 DataBar, Logmars

• 2D bar code

PDF-417, Maxicode, DataMatrix, QR code, Aztech
Font and barcode rotation
0, 90, 180, 270 degree
Printer language
TSPL-EZTM (Compatible to EPL, ZPL, ZPL II)
label type
Continuous roll,distance labels, perforated tags, folded label, black line , cardboard tags, ticket, clothing care labels ( outside rewinded)
Label width
25.4 ~ 116 mm (1"~ 4.5")
label thickness
0.06 ~ 0.30 mm (2.36 ~ 11.81 mil)
label core size
25.4 ~ 76.2 mm (1"~ 3")
label length
5 ~ 25,400 mm (0.20"~ 1,000")
5 ~ 11,430 mm (0.20"~ 450")
5 ~ 2,540 mm (0.20"~ 100")
Environment condition
Operation environment : 5-40 c humidity ( Non-condensed) 25-85%
storage environment: -40-60c humidity ( Non-condensed) 5-90%
Safety regulations
FCC Class A, CE Class A, C-Tick Class A, UL, CUL, TÜV/Safety, CCC, CB
Environment regulations
Comply with RoHS, WEEE
Accessories
Windows labels roll editor software, cd driver and operation Manual files
quick-installation guideline
USB transmission line
power supply line
Factory option
GPIO interface module
Dealer option
labelling rewiding module ( include the roll rewinder and inside labelroller, the max label capacity, 6 inches diameter)
label peel off module ( include the label peel off device, internal label rewinder or stripping sensor)
User option
• Bluetooth module (serial interface)
• 802.11 b/g/n Wireless module (serial interface)
• Regular cutter (full cut guillotine cutter)
• Heavy duty cutter (rotary cutter)
• Care label cutter (rotary cutter)
• KP-200 Plus keyboard display unit
• KU-007 Plus programmable smart keyboard
