Packaging shipping label thermal printing H500B receipt direct thermal printer
Packaging shipping label thermal printing H500B receipt direct thermal printer
Packaging shipping label thermal printing H500B receipt direct thermal printer
Packaging shipping label thermal printing H500B receipt direct thermal printer
Packaging shipping label thermal printing H500B receipt direct thermal printer
Packaging shipping label thermal printing H500B receipt direct thermal printer
Packaging shipping label thermal printing H500B receipt direct thermal printer
Packaging shipping label thermal printing H500B receipt direct thermal printer
Packaging shipping label thermal printing H500B receipt direct thermal printer

Packaging shipping label thermal printing H500B receipt direct thermal printer

Model NO.
H500B
Price:
USD 200.00-215.00 / pieces
Delivery:
FOB
Minimum order quantity:
2 pieces
Supply Ability:
5000 pieces / Quarterly
Country of Origin:
Shenzhen, guangzhou dongguan
Quantity:
  • Products Status:Stock
  • Style:Black And White
  • Use:Barcode Printer
  • Interface Type:USB
  • Place of Origin:CN;GUA
  • Type:direct thermal , thermal sensitive
  • Max Paper Size:108mm (4.25")
  • Black Print Speed:127mm/ sec 5 inches/ sec
  • Color Print Speed:127mm/ sec 5 inches/ sec
  • Max. Resolution:203dpi
  • Brand Name:NO
  • Model Number:H500B
Product Description

Packaging shipping label thermal printing H500B receipt direct thermal printer


XP-H500B thermal transfer barcode printer
(Direct thermal / thermal sensitive printer)
Automatically peelling off direct thermal label printer
1. Double motors design
2. Print speed can reach to 127mm/sec
3. Ribbon capacity 300m, 25.4mm ribbon core (outside)
4. Ribbon instructure module design
5. Super large CPU capacity 4MB Flash, 8MB SDRAM
6. with Micro SD card slot.
7. USB 2.0 standard communication interface
8. Humanalized high grade printer language TSPL-EZ tm, Instruciton set support Eltron r and Zebra R.
9. Include with label sticker editor software and windows driver programme.
Detailed Images
Printer model
XP H500B
Printing method:
direct thermal printing/ thermal sensitive
printing resolution:
203dpi 8 dots/ mm ( other 300dpi)
pirnt width:
108mm
print speed:
127mm ( 5")
Most print length:
2286mm (90")
memory:
4MB FLASH RAM, 8MB SDRAM / Micro SD Flash reader can extend to 4GB.
Interface
USB 2.0 (standard )/ serial port (optional) / parallel (optional)/ network (optional) bluetooth (optional) / wirelss wifi(optional)/TFcard(alternative)
Power supply:
Circumscribed general switch power supply
Imput: AC 100-240V , 1.8 A 50-60HZ
output: DC 24v 2.5A , 60W
Operation switch, button , LED
Power off switch, feed, LED light ( three color) red purple, blue
Sessor
Black mark ( reflective location can be adjustable)
Printer head open sensor
gap distance sensing
Ribbon end sensing
In-built typeface
8 kinds bitmap typeface/ or can use windows fonts download from Internet.
Barcodes:
1D bar code:Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11
2D bar code:PDF-417, Maxicode, DataMatrix, QR code, Aztec
Character enlarge/ rotary:
Horizontally and vertically can amplified 1-10 times, rotary printing ( 0°,90°,180°, 270°)
Printer Language:
TSPL ( EPL, ZPL, DPL)
Medium ( paper) type
Continuous paper, distance paper, fold , perforated tags etc
Medium width:
25.4 mm- 118mm (1"- 4.6")
Medium thickness:
0.06 ~ 0.254 mm (2.36 ~ 10 mil)
label roll inner core
25.4 ~ 76.2 mm (1"~ 3")
Print label length:
10 ~ 2,286mm (0.39"~ 90")
Accessory:
> Windows label editoring software, driver and operation manual CD
> quick -installation guideline
> USB transmission line
> Power supply line
> Circumscribed Voltage automatically exhange power supply server
> rewinder roller, paper fixation panel *2
Factory: (Alternative)
1. Built-in Ethernet server (10/100Mbps) 2. RS-232C (2400-115200 bps) communication interface, 3. Centronics communication port
Customers (alternative)
1. Exernal hanger and 1 inch core paper roller
2. bluetooth module (RS-232C transmission interface)
3. WIFI module
4. Circumscribed external extend panel
5. Cutter
Safety regulation:
FCC,CE, CCC,CB
Weight:
3 kg
Dimension:
303 (D) x 238(W) x198(H)mm
working environment :
5~40℃ (41~104°F), Humidity 25-85%RH ( uncondensed)
Storage:
-40~60℃ (-40~140°F),Humidity 10 ~ 90% ( uncondensed)
Durability:
Printer head one year/ printer head 30miles or within one year , rubber covered roller valid within 1 year.
Packing & Delivery

XP-H500B Net weight estimated : 3.5KG

Similir model XP 480B / H500B
Carton size: 31cm* 29*28cm 7 KG around
