| Printer model | XP 480B | |
| Printing method: | direct thermal printing/ thermal sensitive |
| printing resolution: | 203dpi 8 dots/ mm |
| pirnt width: | 108mm |
| print speed: | 127mm ( 5") |
| Most print length: | 1778mm (70") | |
| memory: | 8MB FLASH RAM, 8MB SDRAM / Micro SD Flash reader can extend to 4GB. |
| Interface | USB 2.0 ( standard) /TF CARD (optional)/ RS-232 ( Factory option) , Etherne t ( Factory option) bluthtooth( Factory option) , Wireless WIFI ( Factory option) |
| Power supply: | Circumscribed general switch power supply Imput: AC 100-240V , 1 A 50-60HZ output: DC 24v 2.5A , 60W |
| Operation switch, button , LED | Power off switch, feed, LED light ( two color) |
| Sessor | Black mark ( reflective location can be adjustable)
Printer head open sensor
gap distance sensing |
| In-built typeface | 8 kinds bitmap typeface/ or can use windows fonts download from Internet. |
| Barcodes: | Code128 subsets A.B.C,Code128UCC, EAN128, Interleave 2 of 5,Code 39,Code 93, EAN-13, EAN-8, Codabar, POSTNET, UPC-A, UPC-E, EAN and UPC 2(5) digits, MSI, PLESSEY, China Post, ITF14, EAN14, Code 11, TELPEN, PLANET, Code 49, Deutsche Post Identcode, Deutsche Post Leitcode, LOGMARS
2D bar code:CODABLOCK F mode, DataMatrix, Maxicode, PDF-417, Aztec, MicroPDF417, QR code, RSS Barcode (GS1 Databar) |
| Character enlarge/ rotary: | Horizontally and vertically can amplified 1-10 times, rotary printing ( 0°,90°,180°, 270°) |
| Printer Language: | TSPL ( EPL, ZPL, DPL) |
| Medium ( paper) type | Continuous paper, distance paper, fold , perforated tags etc |
| Medium width: | 20mm- 118mm (0.78"- 4.6") |
| Medium thickness: | 0.06 ~ 0.25 mm (2.36 ~ 9.8 mil) |
| label roll inner core | 25.4 ~ 76.2 mm (1"~ 3") |
| Print label length: | 10 ~ 1,778 mm (0.39"~ 70") |
| Accessory: | > Windows label editoring software, driver and operation manual CD > quick -installation guideline > USB transmission line > Power supply line > Circumscribed Voltage automatically exhange power supply server
> rewinder roller, paper fixation panel *2 |
| Factory: (Alternative) | 1. Bluetooth 2. N RTC 3. WIFI 4. Serial 5. TF Card (SD) |
| Customers (alternative) | 1. Exernal hanger and 1 inch core paper roller 2. External label hanger extend panel 3. Electronic single box |
| Safety regulation: | FCC,CE, CCC,CB |
| Weight: | 2.05kg |
| Dimension: | 219.03(D) x 189.62(W) x178.5(H)mm |
| working environment : | 5~40℃ (41~104°F), Humidity 25-85%RH ( uncondensed) |
| Storage: | -40~60℃ (-40~140°F),Humidity 10 ~ 90% ( uncondensed) |
| Durability: | Printer head one year/ printer head 30miles or within one year , rubber covered roller valid within 1 year. |
