Printer model | TTP-2410 MU | TTP-346MU | TTP644MU |
Printing resolution | 8 dots/mm (203 DPI) | 12 dots/mm (300 DPI) | 24 dots/mm (600 DPI) |
Printing method | Thermal Transfer printing & Direct Thermal |
Max. print speed | 356 mm (14")/sec | 254 mm (10")/sec | 102 mm (4")/sec |
Max. print width | 4.09"104mm |
Printer shell | Aluminium alloy structure , metal shell , with an open window design |
Physical Dimension | 270 mm (W) x 308 mm (H) x 515 mm (D) 10.63"(W) x 12.13"(H) x 20.28"(D) |
Weight | 15KG (33.07 lbs) |
Label Capacity Diameter | 208.3 mm (8.2") OD |
Ribbon | 600 m max. OD 90 mm, 1"core (inking outside or inside suitable) |
Ribbon width | 25.4 mm ~ 114.3 mm (1"~ 4.5") |
Processor | 32 bit CPU |
Memory | • 128 MB Flash memory • 128 MB SDRAM • SD Flash card with expandable card extend up to 32 GB |
Communication interface | • Serial interface RS-232 • Parallel port• USB 2.0 • In-built Ethernet Server • USB host, support stand-alone operation keyboard, and barcode scanner • GPIO (alternative option) • Bluetooth (user alternative option) • 802.11 b/g/n Wireless transmission (user option) |
Power Supply | In-built Power Voltage automatically switching power supply • Input: AC 100-240V, 2A, 50-60Hz • Output: DC 24V, 5A, 120W |
Operation panel | Display 128*64 Pixel backing light |
Operation switch-off, button | one switch-off power supply, 6 buttons ( Menu, Pause, Feed, Up, Down, Select) |
Sensor | Label distance sensor ( Penetration, location adjustable) black line sensor ( reflective , location adjustable) ribbon end-up usage ribbon transmit speed printing head up and down style sensor |
Real time clock | standard |
In-built typeface | • 8 alpha-numeric bitmap fonts • Monotype Image® true type font engine with one CG Triumvirate Bold Condensed scalable font |
Barcode | • 1D bar code
Code 39, Code 93, Code 128UCC, Code 128 subsets A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13,
EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST,
GS1 DataBar, Logmars
• 2D bar code
PDF-417, Maxicode, DataMatrix, QR code, Aztech |
Font and barcode rotation | 0, 90, 180, 270 degree |
Printer language | TSPL-EZTM (Compatible to EPL, ZPL, ZPL II) |
label type | Continuous roll,distance labels, perforated tags, folded label, black line , cardboard tags, ticket, clothing care labels ( outside rewinded) |
Label width | 25.4 ~ 116 mm (1"~ 4.5") |
label thickness | 0.06 ~ 0.30 mm (2.36 ~ 11.81 mil) |
label core size | 25.4 ~ 76.2 mm (1"~ 3") |
label length | 5 ~ 25,400 mm (0.20"~ 1,000") | 5 ~ 11,430 mm (0.20"~ 450") | 5 ~ 2,540 mm (0.20"~ 100") |
Environment condition | Operation environment : 5-40 c humidity ( Non-condensed) 25-85%
storage environment: -40-60c humidity ( Non-condensed) 5-90% |
Safety regulations | FCC Class A, CE Class A, C-Tick Class A, UL, CUL, TÜV/Safety, CCC, CB |
Environment regulations | Comply with RoHS, WEEE |
Accessories | Windows labels roll editor software, cd driver and operation Manual files
quick-installation guideline
USB transmission line
power supply line |
Factory option | GPIO interface module |
Dealer option | labelling rewiding module ( include the roll rewinder and inside labelroller, the max label capacity, 6 inches diameter)
label peel off module ( include the label peel off device, internal label rewinder or stripping sensor) |
User option | • Bluetooth module (serial interface)
• 802.11 b/g/n Wireless module (serial interface)
• Regular cutter (full cut guillotine cutter)
• Heavy duty cutter (rotary cutter)
• Care label cutter (rotary cutter)
• KP-200 Plus keyboard display unit
• KU-007 Plus programmable smart keyboard |
